Description
Overview
- Roller length 1750mm
- Roller Ø 365mm
- Heating EL
- Output 90kg/h
Specifications
| ROTARY IRONERS | PM 1418 |
| Roller diameter [mm] | 365 |
| Roller length [mm] | 1750 |
| Aluminium heater plate | • |
| Cover: Steel wool padding with ARAMID needle felt cloth | • |
| Spring leaf padding with ARAMID Molton | ° |
| Useable roller width with optional spring leaf padding [mm] | 1690 |
| Exhaust ducting Ø [DN] | 75 (Gas 120) |
| Electrically heated machines: | |
| 3N AC 380-415 V 50-60 Hz | • |
| Heater rating [kW] | 21.4 |
| Total connected load [kW] | 22.2 |
| Fuse rating [A] | 3 x 50 |
| Gas heated machines: | |
| 3N AC 380-415 V 50 Hz | • |
| Total electrical load [kW] | 0.9 |
| Fuse rating [A] | 3 x 10 |
| Output | |
| Roller speed [m/min] | 1.5–6.0 |
| Roller speed [rpm] | 1.3–5.2 |
| 25% residual moisture [up to kg/h] | 90 |
| 50% residual moisture [up to kg/h] | 54 |
| Laundry feed | |
| To the front | • |
| To the front via return feed module | ° |
| Dimensions, weight | |
| External dimensions H/W/D [mm] | 1318/2540/1150 |
| Weight [kg] | 386 |
• – Standard Feature
° – Optional
x – Not Available
