Classeq P500A Pass Through Dishwasher

The P500A is a pass through dishwasher, suitable for high volume environments. The machine can wash up to 720 plates per hour and features a continuous hood cleaning system.

  • Three wash programmes
  • Liquid crystal display
  • Shortest cycle 1.5 mins
  • Built in water softener (optional)


Key features

  • Three wash programmes
  • Wash capacity of 720 plates per hour
  • Pass through system
  • Built-in water softener (optional)

Other Classeq models are available upon request.


Commercial Pass Through Dishwasher P500A
Theoretical max racks per hour 40
Rack size 500mm
Max no of plates per rack 18
Shortest programme 1.5 mins
Integrated water softener Optional
Water Connections
Water supply connection 3/4″
Minimum allowed supply water pressure 2.0 bar
Required water flow rate 11L/min OR 4L/min (with water softener)
Electrical specifications
Operating voltage standard 380-415AC/50/3N
Operating voltage optional 220-240AC/50/1N
Amps required – 1 phase 30A
Amps required – 3 phase 12A
Dimensions / Weight
Height hood open 1890-1960mm
Height hood closed 1470-1520mm
Width 630mm
Depth 720mm
Weight 130kg
